Description
Heavy duty trolley style hydraulic jack for lifting of motor vehicles, trailers or other heavy loads and equipment so maintenance or other procedures can be performed.
Features:
- Folded and flanged solid steel frame construction gives rigidity and prevents twisting under load
- One-piece steel lifting arm for greater strength
- Heavy duty cast iron fixed front castor wheels
- Rear 360-degree rotation cast iron swivel castors for efficient manoeuvrability
- 360-degree rotation lifting sadle
- Unique low rider profile gives suitability for sports and lowered vehicles
- 1-piece jacking handle for extra stroke and manoeuvrability
- Powder coated finish for durability and corrosion resistance
- Owner’s manual included
- Australian standards compliance
Application:
- Heavy duty trolley style hydraulic jack for lifting of motor vehicles, trailers or other heavy loads and equipment so maintenance or other procedures can be performed. Unique low-profile design allows clearance for the lifting of sports and lowered vehicles.
Specifications:
- Working Load limit: 1700kg
- Maximum Raised Height: 359mm
- Minimum Lowered Height: 89mm
- Overall length: 550mm
- Front Frame width: 110mm
- Front Width including castors: 170mm
- Front castor width: 25mm
- Wheelbase: 440mm
- Australian Standard: AS/NZS 2615:2016
- WEIGHT(NET):14KG
Safety Note:
- The jack must be used on hard level surfaces
- The wheels of the vehicle being lifted to be chocked
- Do NOT put a portion of your body under a vehicle supported by a jack
- No person should remain in a vehicle that is being jacked
- Do NOT exceed working load limit
